BL-100S |
Fail Safe Electric Bolt with Magnetic Feature |
| Face Plate : |
205L x 35W x 40H (mm) |
| Strike: |
90L x 25W x 2H (mm) |
| Bolt: |
16mm DIA, stainless stell 16mm throw |
| Voltage: |
DC12V |
| Current: |
Start 950mA, Standby 80mA |
| Suitable for: |
Wooden, glass, metal or fire proof door |
| Fail Safe: |
Locked when energized |
| Weight: |
0.7kg |
|
BL-100 |
Fail Safe Electric Bolt with Magnetic Feature |
| Face Plate : |
205L x 35W x 40H (mm) |
| Strike: |
90L x 25W x 2H (mm) |
| Bolt: |
16mm DIA, stainless stell 16mm throw |
| Voltage: |
DC12V |
| Current: |
Start 900mA, Standby 150mA |
| Suitable for: |
Wooden, glass, metal or fire proof door |
| Fail Safe: |
Locked when energized |
| Time: |
0, 2.5, 5, 9 Sec |
| Weight: |
0.7kg |
|
BL-200 |
Fail Safe Electric Bolt with Monitoring LED |
| Face Plate : |
205L x 35W x 40H (mm) |
| Strike: |
90L x 25W x 2H (mm) |
| Bolt: |
16mm DIA, stainless stell 16mm throw |
| Voltage: |
DC12V |
| Current: |
Start 900mA, Standby 150mA |
| Suitable for: |
Wooden, glass, metal or fire proof door |
| Fail Safe: |
Locked when energized |
| Time: |
0, 2.5, 5, 9 Sec |
| Weight: |
0.7kg |
|
BL-300 |
Fail Safe Electric Bolt with Magnetic Feature |
| Face Plate : |
205L x 35W x 40H (mm) |
| Strike: |
90L x 25W x 2H (mm) |
| Bolt: |
16mm DIA, stainless stell 16mm throw |
| Voltage: |
DC12V |
| Current: |
Start 900mA, Standby 150mA |
| Suitable for: |
Wooden, glass, metal or fire proof door |
| Fail Safe: |
Locked when energized |
| Time: |
0, 2.5, 5, 9 Sec |
| Weight: |
0.7kg |
|
BL-400 |
Fail Safe Electric Bolt specially for Auto-door |
| Face Plate : |
205L x 35W x 40H (mm) |
| Strike: |
90L x 25W x 2H (mm) |
| Bolt: |
16mm DIA, stainless stell 16mm throw |
| Voltage: |
DC12V |
| Current: |
Start 800mA, Standby 300mA |
| Suitable for: |
Auto-door door |
| Fail Safe: |
Locked when energized |
| Time: |
0, 2.5, 5, 9 Sec |
| Weight: |
0.8kg |
|
BL-500 |
Fail Safe Electric Bolt with Adjustable Feature |
| Face Plate : |
205L x 35W x 40H (mm) |
| Strike: |
100L x 35W x 3H (mm) |
| Bolt: |
16mm DIA, stainless stell 16mm throw |
| Voltage: |
DC12V, low power |
| Current: |
Start 900mA, Standby 100mA |
| Suitable for: |
Wooden, glass, metal or fire proof door |
| Fail Safe: |
Locked when energized |
| Weight: |
0.8kg |
|
BL-600 |
Fail Secure Electric Bolt with Mort Lock Cylinder |
| Face Plate : |
260L x 35W x 48H (mm) |
| Strike: |
100L x 25W x 2H (mm) |
| Bolt: |
16mm DIA, stainless stell 16mm throw |
| Voltage: |
DC12V |
| Current: |
Start 900mA, Standby 150mA |
| Suitable for: |
Heavy, Glass, Metal or Wood Door |
| Fail Sacure: |
Unlocked when energized |
| Time: |
0, 3, 6, 9 Sec |
| Weight: |
1.3kg |
| |
|
|
BL-700A |
Fail Safe Electric Bolt with Magnetic Feature |
| Face Plate : |
205L x 25W x 28H (mm) |
| Strike: |
100L x 25W x 3H (mm) |
| Bolt: |
16mm DIA, stainless stell 16mm throw |
| Voltage: |
DC12V |
| Current: |
Start 950mA, Standby 150mA |
| Suitable for: |
Heavy, Glass, Metal or Wood Door |
| Fail Safe: |
Locked when energized |
| Time: |
0, 3, 6, 9 Sec |
| Weight: |
1kg |
|
BL-700B |
Fail Secure Electric Bolt with Magnetic Feature |
| Face Plate : |
205L x 25W x 28H (mm) |
| Strike: |
100L x 25W x 3H (mm) |
| Bolt: |
16mm DIA, stainless stell 16mm throw |
| Voltage: |
DC12V |
| Current: |
Start 950mA, Standby 150mA |
| Suitable for: |
Heavy, Glass, Metal or Wood Door |
| Fail Secure: |
Unlocked when energized |
| Time: |
0, 3, 6, 9 Sec |
| Weight: |
1kg |
|
|
|
